Decanter Liquid - Liquid - Solid 3 Phase Centrifuge for Kitchen Waste Oil Separation
Description
Horizontal structure 3-phase liquid-liquid-solid centrifuges are commonly known as tricanters. These machines make use of the principle that the heavy liquid, light liquid, and solid phases have different densities and are insoluble in the mixed liquid. As a result, they have different sedimentation speeds in the centrifugal force field or gravity force field, which can be used to separate stratification or cause the solid particles in the liquid to deposit. Tricanters are widely used for separating fish oil, palm oil, kitchen waste oil, and other liquids across the world.
Separation principle
The decanter is powered by two motors. The main motor rotates the bowl and the differential mechanism housing via a belt, while the auxiliary motor rotates the input shaft of the differential mechanism via a belt pulley. This, in turn, drives the helical after speed adjustment. Consequently, the bowl and helical rotate in the same direction, but with different speeds due to the differential mechanism.
Competitive Advantages
- 3phase liquid-liquid-solid separation
- Robust quality
- Outstanding separation effect
- Wide usage in the fish oil and fishmeal field
- Corrosion-resistant and resistant key parts
- Flexible length-to-diameter model for customized.
- Famous and reliable electrical components
Specifications
| Model | Drum | G-force | Capacity (m3/h) | Max solid discharge (m3/h) | Power (kW) | Weight (kg) | Overall size (L×W×H) (mm) |
| Diameter (mm) | Speed (rpm) | Length (mm) | Length-to-diameter rate |
| PDCS-16-3 | 400 | 3650 | 1200 | 3 | 3000 | 1~5 | 1.5 | 18.5/7.5 | 2350 | 2990 ×960 × 1205 |
| PDCS-16-4.5 | 400 | 3650 | 1800 | 4.5 | 3000 | 2~25 | 2 | 22/7.5 | 2500 | 3890 × 1020 × 1205 |
| PDCS-17 | 420 | 3300 | 1680 | 4 | 2550 | 2~25 | 2.5 | 30/11 | 3610 | 4050×1270×1100 |
| PDCS-18 | 450 | 3450 | 2000 | 4.8 | 3000 | 3~35 | 3 | 37/22 | 3000 | 4297 × 1080 × 1385 |
| PDCS-20 | 500 | 3000 | 2000 | 4 | 2500 | 5~45 | 3.2 | 37/22 | 3800 | 4330 × 1140 × 1470 |
| PDCS-21 | 530 | 2900 | 2280 | 4.3 | 2500 | 15~65 | 5 | 55/30 | 5000 | 4924 × 1170 × 1540 |
More pictures
Guarantee
Peony Centrifuge is a company that specializes in producing machinery, equipment, and facility construction. Our primary goal is to ensure that we provide the best quality products while also rewarding our customers. We are dedicated to going the extra mile for our customers by offering exceptional services and building trust. Our commitment to excellence and our faith in our customers is what drives us to continuously strive for improvement.
Our services
1. We offer a 12-month guarantee period from the date the machine arrives.
2. We have abundant spare parts in stock that are available for you.
3. Our technicians can be dispatched for overseas service if needed.
4. We provide 7*24 hours of technical consultation.
5. We offer training for your workers, either in our factory or yours.
6. We will perform routine tracing until the machine works properly.
7. We will remind you to perform normal maintenance.
8. Your suggestions, comments, and reflections will be treated as a priority.
9. If you require, our marketing team will visit you during our visit to your country.
